PUGS41 Extremely Flexible Polyurethane Hose

Abrasion resistant ester-based extremely flexible polyurethane hose(wall thickness between the spirals ca. 0,4mm), copper plated spring steel spiral embedded into wall, excellent spring back performance.

key word:

Polyurethane hose flexible hose flexible polyurethane hose flexible PU hose TPU ducting Flex hose suction hose transport hose ventilation hose conveying hose TPU hose welding fume hose pressure hose industrial hose

Category:

Products

PU Steel Wire Flexible Hose

Enclosure:

Hotline:

Hotline:

PUGS41 Extremely Flexible Polyurethane Hose

Product

Inner Diameter (mm)	Wall thickness (mm)	Overpressure (bar)		Standard length (m)
50	0.4	0.695	0.240	10
60	0.4	0.600	0.200	10
64	0.4	0.535	0.170	10
70	0.4	0.490	0.160	10
75	0.4	0.470	0.150	10
80	0.4	0.435	0.120	10
90	0.4	0.390	0.100	10
100	0.4	0.350	0.080	10
110	0.4	0.330	0.075	10
120	0.4	0.290	0.070	10
125	0.4	0.280	0.055	10
150	0.4	0.175	0.045	10
175	0.4	0.165	0.040	10
200	0.4	0.130	0.030	10
225	0.4	0.115	0.025	10
250	0.4	0.105	0.025	10
300	0.4	0.100	0.010	10

Application

Universal and abrasion-proof suction and transport hose, especially suitable:

* for abrasive solids such as dust,powder, fibres, chips and granulates

* for gaseous and liquid media,drinks,syrup

* for de-dusting and suction plants, industrial vacuum cleaners, suction of paper and textile fibres

* for woodworking

^Properties

^{* Microbes and hydrolysis resistant}
^{* Good tensile and abrasion strengths and ultimate elongation

* Light weight, compressible 3:1 or 4:1

* Excellent resistance to abrasion, UV}
^{* Free of softeners, halogen}

Material *Ester-Polyurethane

Thickness *0.4MM

Temperature * -40℃ to 90℃ (Short-term 125°C)

The tolerance for all parameters is 5%. All parameters apply to room temperature (approx. 22 ° C).

Application

wood making

solid collection

air suction
