PUGP-MBG Food Grade Smooth Inner Flexible Polyurethane Suction Hose
Very smooth inner, extruded ester-based polyurethane hose(FDA), transparent with stainless spring steel spiral.
key word:
Category:
Enclosure:
Hotline:
Hotline:
PUGP-MBG Food Grade Smooth Inner Flexible Polyurethane Suction Hose
Suitable
Food and beverage dispensing, air, water, coolant, car wash, deionized water systems and other clear flow applications
Standrad
Available in lengths of 10 meters. Special format by request up to 20 meters
Material
Available in lengths of 10 meters. Special format by request up to 20 meters.
Thickness
Min.: 3.5mm
Max.: 5.5 mm (Customized）
Temperature
-40℃ to 90℃ (Short-term 125°C)
Features
Extremely flexible with great abrasion resistance
Smooth interior assures minimal friction loss, efficient air flow & elimination of material build-up
Puncture & tear resistant with high tensile strength
Good low temperature flexibility
|
Inner Diameter (mm) |
Wall Thickness (mm) |
Overpressure (bar) |
Vacuum (bar) |
Standard Length (m) |
|
| 25 | 3.5 | 5.00 | 1.00 | 50 | |
| 32 | 4.0 | 5.00 | 1.00 | 50 | |
| 38 | 4.0 | 4.00 | 1.00 | 50 | |
| 45 | 4.0 | 4.00 | 1.00 | 50 | |
| 51 | 4.0 | 4.00 | 1.00 | 50 | |
| 64 | 4.5 | 2.00 | 1.00 | 50 | |
| 75 | 5.0 | 2.00 | 0.50 | 50 | |
| 100 | 5.5 | 1.00 | 0.50 | 50 | |
The tolerance for all parameters is 5%. All parameters apply to room temperature (approx. 22 ° C).
Recommendations
PUGS04 Very Light Flexible Polyurethane Hose
PUGS04-M Very Light Flexible Polyurethane Hose
PUGS41 Extremely Flexible Polyurethane Hose
PUGS06 Light Flexible Polyurethane Hose
PUGS06-M Light Flexible Polyurethane Hose
PUGS09 Medium Weight Flexible Polyurethane Hose
